P/N
CA-1I7-00F1WN-03
Séries
View
Model
View 71 TG ARGB
TYPE DE BOITIER
Full Tower
DIMENSIONS (H x L x P)
577 x 274 x 592 mm
(22.7 x 10.8 x 23.3 inch)
POIDS NET
19.3 kg / 42.55 lb
PANNEAU LATÉRAL
5mm Tempered Glass x 4 (Left & Right & Front & Top)
COULEUR
Exterior & Interior : Black
MATÉRIEL
SPCC
SYSTÈME DE REFROIDISSEMENT
Front (intake) :
140 x 140 x 25 mm ARGB fan (1000rpm, 22.8 dBA) x 2
Rear (exhaust) :
140 x 140 x 25 mm ARGB fan (1000rpm, 22.8 dBA)
BAIES DE LECTEUR

2.5” x 4 or 3.5”x4 (HDD Rack)
2.5”x 6 or 3.5” x 3
FENTES D'EXTENSION
8+2
CARTES MÈRES
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13”(E-ATX)
PORT E/S
USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, RGB Button x 1
Bloc Alimentation
Standard PS2 PSU (optional)
SOUTIEN DES VENTILATEURS
Front:
3 x 120mm , 2 x 140mm
Top:
3 x 120mm , 3 x 140mm
Rear:
1 x 120mm, 1 x 140mm
Bottom:
2 x 120mm
SUPPORT RADIATEUR
Front:
1 x 360mm , 1 x 420mm
Top:
1 x 360mm , 1 x 420mm
Rear:
1 x 120mm, 1 x 140mm
Right:
1 x 360mm, 1 x 420mm
Bottom:
1 x 240mm
AUTORISATION
CPU cooler height limitation: 190mm
VGA length limitation: 310mm(With HDD Rack)
　　　　　　　　　 410mm(Without HDD Rack)
PSU length limitation: 220mm (Without Bottom Fan)
