Model: X96H avec TIVIMATE
CPU: H603 Quad Core 64-bit Cortex- A53
GPU: High-performance multi-core GPU Mali T720
RAM: 2GB
ROM: 16GB
WiFi: IEEE 802.11 b/g/n/ac; 2.4G / 5G 2*2 mimo
bluetooth: bluetooth 4.1 +HS; Support Voice Remote
Interface:
1*HDMI OUT (One HDMI 2.0a TX)
1*HDMI IN (One HDMI 1.4 TX input)
1*AV OUT (486i/576i standard definition output)
3*USB (1* USB 3.0; 1*USB 2.0; 1*USB2.0 OTG)
1*RJ45 (Ethernet Interface; Support 10/100M)
1*OPTICAL (One Optical output)
1*TF CARD (Support 4GB/8GB/16GB/32GB/64GB)
Power: DC 5V/2A; LED indicator. Working, blue
System: Android 9.0
Video:
Allwinner Video Engine (AVE) with dedicated hardware decoders and encoders
Support multi-video decoder up to 4Kx2K at 60fps+1x1080P at 60fps
Supports multiple "secured" video decoding sessions and simultaneous decoding and encoding
Video/Picture Decoding
- H265/HEVC Main/Main10 profile at Level5.2 High-tier;4K at 60fps, up to 6Kx4K at 30fps
- H264/AVC BP/MP/HP at level5.1, MVC, 4K at 30fps
- VP9, Profile 0/2, 4K at 30fps
- VP6/VP8, 1080P at 60fps
- MPEG1/MPEG2 SP at ML, MP at HL, 1080P at 60fps
- MPEG4 SP at level 0~3, ASP at level 0~5, GMC, short header format, 1080P at 60fps
- AVS+/AVS JIZHUN profile at level 6.0, 1080P at 60fps
- VC-1 SP at ML, MP at HL, AP at level 0~3, 1080P at 60fps
- Supports Frame Buffer Compression (FBC)
- Output pixel format configurable, YUV420/YV12/NV12/
- Real-time image decoding- Maximum resolution up to 65536 x 65536
- Integrated JPEG hardware decoder
- Configurable output pixel format- YUV420/YV12/NV12/
Audio:
MPEG-1, MPEG-2 (L1/L2/L3), MP3, AAC-LC, HE AAC V1/V2, APE, FLAC, OGG, AMR-NB, AMR-WB, G.711 (u/a) decoding
G.711(u/a), AMR-NB, AMR-WB, AAC-LC encoding
