Specification:<>

MPPT,LCD display,RS485,12/24V system voltage<>

• Innovative MPPT technology,tracking efficiency 99.9%,conversion efficiency up to 97%<>

• Real-time display the operational data and working status of the controller in digital,graphic and textual forms by a large LCD<>

• AGM,Gel,Liquid battery to choose<>

• Two navigation buttons,easy to implement various operations<>

• 12V/24V automatic,recognition,Temperature compensation,Perfect EMC design<>

• Four stage charge way:MPPT,boost,equalization,float<>

• Full automatic electronic protect function<>

Specification:<>

 <> MT1050EU

 <>

 <>

 <>

 <>

 <>

 <>

 <>

 <>

Battery Parameters<>

System voltage12VMax charging current10AMPPT charging voltage<14.5V@25Boost voltage14.5V@25Equal voltage14.8V@25Float voltage13.7@25Low voltage disconnect10.8~11.8V;SOC1~5Low voltage reconnect11.6~12.8VOver charge protect15.5VMax battery voltage20VTemp copensation-4.17mV/K per cell(Boost,Equal),-3.33mV/K per cell(Float)Battery typeAGM,Liquid,GEL

 <>

 <>

 <>

Panel Parameters<>

Max solar voltage45VMax input power130WDusk/Dawn detect volt.8.0VMPPT tracking range(Battery Voltage+1.0V)~Voc*0.9*

 <>

 <>

Load<>

Output current10AUSB interface5V,2AWork modeStandard,D2D,Street lamp,User-defined mode

 <>

 <>

 <>

 <>

 <>

 <>

System Parameters<>

Max tracking efficiency>99.9%Max charge conversion96.5%Dimensions(mm)189*96*53Weight480gSelf consumption7mAAmbient temperature-20~+55Storage temperature-25~+80Ambient humidity0~100%RHProtection degreeIP32Max altitude4000m

 <>
